Three-Way Control Valve with HART Communication 20-100 Psi

VALVE STYLE Globe valve

USAGE

• Low-pressure service
• Throttling service
• Cryogenic service

VERSION ANSI

MEDIUM TEMPERATURE -196 to 425 °C / -320.8 to 797 °F

SUPPLY Pneumatic

VALVE SIZE NPS ½ to NPS 12

PRESSURE RATING Class 125 to Class 300

LINING without

Options

• Welding ends
• Adjustable packing
• Flow divider or AC-trim for noise reduction
• Insulating section or bellows seal
• Heating jacket
• Perforated plug
• Silencers

Special features

• Consisting of globe valve and actuator
• Optionally including RFID transponder with unique marking according to DIN SPEC 91406

Accessories

• Type 2 N Strainer
• Type 2 NI Strainer

Special features Type 3241 Globe Valve operated with

• Type 3271 Pneumatic Actuator (Type 3241-1 Control Valve)
• Type 3277 Pneumatic Actuator (Type 3241-7 Control Valve)

Valve body made of

• Cast iron
• Cast steel, cast stainless steel or cast cold-resisting steel
• Forged steel or forged stainless steel
• Special materials Undivided valve bonnet up to NPS 6

Valve plug

• Metal seal
• Soft seal
• High-performance metal seal Optional with RF ID tags with one-to-one device marking according to DIN SPEC 91406.

The control valves with their modular design can be equipped with various accessories: Positioners, limit switches, solenoid valves and other accesso ries according to IEC 60534-6-1 1) and NAMUR recommen dation. Refer to Information Sheet u T8350 for more details. Versions Standard version for temperatures ranging from 14 to 428 °F (–10 to +220 °C) – Type 3241-1 (Fig.1, Fig. 3) · NPS ½ to 12 · With Type 3271 Pneumatic Actuator (see Data Sheets u T 8310-1, u T 8310-2 and u T 8310-3) – Type 3241-7(Fig. 2, Fig. 4) · NPS ½ to 6 · With Type 3277 Pneumatic Actuator for integral positioner attachment (see Data Sheet u T 8310-1
